JA-100K centrala
Šifra: 31
- Proizvod iz grupe: Jablotron 100
- Proizvođač: Jablotron
Napomena: Artikal je informativnog karaktera, mogu da kupuju samo sertifikovani instalateri.
JA-100K centrala -Protivprovalni, protivpožarni, protivpoplavni sistem + sistem pametne kuće * Besplatan Cloud, SMS i Push Up obaveštenja * Kontrola preko aplikacije, računara ili tastature * Auto-dijagnostika, tačan prikaz stanja baterija * LAN konekcija * do 32 BUS adrese * do 32 korisnika * 4 particije * SMS i glasovni izveštaji iz memorije za do 8 korisnika *
Control panel power supply | 230 V, 50 Hz, max. 0.1 A, protection class II |
---|---|
Back-up battery | 12 V / 2.6 Ah maximum battery charging time 72 h max. continuous consumption from the control panel: 400 mA max. continuous consumption for backing up 12 hours (battery 2.6 Ah) |
LAN off | 125 mA |
LAN on | 85 mA |
Dimensions | 268 x 225 x 83 mm |
Power supply unit | type A (EN 50131-6) |
Operating frequency (with a JA-110R module) | 868 MHz ISM band |
Attempt to find the code Alarm | after 10 wrong code entries |
Event history: | approx. 7 million latest events, incl. date and time |
Classification | security class 2 according to EN50131-1, EN 50131-3, EN 50131-6, EN 50131-5-3 |
Environment | II. indoor, general in accordance with EN 50131-1 |
Operating temperature range | -10 to +40 °C |
Radio emissions | ETSI EN 300220 (module R), ETSI EN 301 419-1, EN 301 511 (GSM) |
EMC | EN 50130-4, EN 55022, ETSI EN 301 489-7 |
Safety | EN 60950-1 |
Operation conditions | ČTÚ VO-R/10/04.2012-7, ČTÚ VO-R1/12.2008-17 |
