JA-151ST-A-AN kombinovani detektor požara

Šifra: 8342

Proizvod iz grupe: Jablotron 100
Proizvođač: Jablotron

Napomena: Artikal je informativnog karaktera, mogu da kupuju samo sertifikovani instalateri.

Bežični, kombinovani detektor požrara. Po potrebi može da bude samo optički, samo termički, a fabrički dolazi kao optičko-termički. Boja: antracit. Mogućnost dodavanja eksterne antene-AN868 za bolji domet. Napajanje 3x 1.5VAA alkalne baterije. Ugrađena sirena za uzbunu.

Power	3 x Alkaline battery type LR6 (AA) 1.5 V/2.4 Ah 3 x Lithium battery type FR6 (AA) 1.5 V/3.0 Ah Please note: Batteries are not included
Typical lifetime	up to 3 years
Communication band	868.1 MHz, Jablotron protocol
Effective Radiated Power (ERP)	10 mW
Communication range	approx. 300 m (open area)
Dimensions	diameter 126 mm, height 50 mm
Weight	150 g
Smoke detection	optical light scattering
Smoke detector sensitivity	m = 0.11 ÷ 0.13 dB/m pursuant to EN 14604:2005, EN 54-7
Heat detection	class A1 according to EN 54-5
Alarm temperature	+60 °C to +65 °C
Operating temperature range	-10 °C to +70 °C
Complies with	EN 54-5, EN-54-7, EN-25
Also complies with	ETSI EN 300 220-2, EN 50130-4, EN 55022 and EN 60950-1
Can be operated according to	ERC REC 70-03
Recommended screw	2x o 3.5 x 40 mm (countersunk head)
