JB-128N modul za podno grejanje

Šifra: 8511

Proizvod iz grupe: Jablotron 100
Proizvođač: Jablotron

Napomena: Artikal je informativnog karaktera, mogu da kupuju samo sertifikovani instalateri.

Jedinica za nezavisno uključivanje do 12 termoelektričnih glava za podno grejanje toplom vodom, zatim razne izvore toplote i cirkulacione pumpe na osnovu uputstava sa termostata u sistemu. Jednostavna instalacija direktno u podni razvodnik.

Thermoelectric heads
Supply voltage	230 V AC, 50 Hz
Power consumption of the device (without heads and pump)	max. 2.3 W / idle 0.8 W
Maximum supply current	1.8 A
Recommended protection (circuit breaker)	4A type B
Connection to the system	12 V DC (8 to 15 V) control panel bus
Supply voltage	230 V AC, 50 Hz
Maximum power input	2 W
Maximum current consumption	300 mA after 200 ms
Output protection for headers	0.8 A, type T
Number of outputs	12
Safety thermostat
NC contact load capacity	1 A / 250 V AC
Output for circulator:
Maximum switching current	1 A / 230 V AC
Protection class	II
Mounting type	Wall / pipe / DIN rail
Dimensions	245 x 90 x 50 mm
Degree of protection IP	IP20
Environment	indoor general
Relative humidity	max. 85 % (non-condensing)
Operating temperatures (ambient)	5° C to +45 °C
In compliance with	EN 50130-4, EN 55032, EN 62368-1, EN IEC 63000, EN 60730-1
