1/2.7" 5MP 2880×1620/30fps, MJPEG+H.264+H.265+
2.8-12mm motor-zoom (30.6° - 104.1°), AF
Colour: 0.003 Lux, 50m IR distance, White LED up to 10m
Two-way audio, Microphone + Speaker, alarm flash light
120dB WDR, MicroSD card (up to 256GB)
Intrusion Prevention Cross Line, Intrusion, Enter Area, Leave Area
Power: 12V DC ±10%/PoE (802.3at) - Power Cons: 18W
-20°C - +60°C IP66 Ø133x269.4mm 1,13Kg, 4 KV surge protection
— 1/2.7" CMOS Image Sensor, max. 2880×1620/30fps
— 4x motorized zoom (2.8-12mm), auto focus
— Angle of view(H): 30.6°(wide) - 104.1°(tele)
— MJPEG+H.264+H.265+SmartEncoding compression
— Colour: 0.003 Lux, 0 Lux IR On, 50 m IR distance, White LED light distance up to 10m
— Triple streams
— Two-way audio, Microphone + Speaker, Blue/Red colour alarm flash light
— 2D/3D DNR, 120dB WDR
— Motion Detection-4 areas, Privacy Mask-8 areas, Up to 8 OSDs
— Embedded smart algorithm ,
— Smart intrusion Prevention Cross Line, Intrusion, Enter Area, Leave Area
— Pan Range 345°, 0.1°/s ~ 50°/s, Preset speed: 50°/s
— Tilt Range –10° ~ +110°, Tilt Speed: 0.1° ~ 40°/s, Preset speed: 40°/s
— Number of Preset 256
— Network: 1xRJ45 10M/100M Base-TX Ethernet
— MicroSD card (up to 256GB)
— Power: 12V DC ±10%/PoE (802.3at) - Power Cons: 18W
— Working Environment -20°C - +60°C
— Ingress Protection IP66
— Dimension: Ø133x269.4mm , 1,13Kg, 4 KV surge protection
— Integrated wal Mounting Bracket
— Compatible Junction Box: TR-JB07-D-IN
— Pole Mount Adapter: TR-UP06-B-IN
